Corebai Microelectronics-Amplifiers-CBM8554AS14

Description

Number of Channels;Four channels/Quiescent Current;180uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;1.8MHz/Common Mode Rejection Ratio(CMRR);110dB/Ib - Input Bias Current;20pA/Vos - Input Offset Voltage;30uV/Slew Rate;0.95V/us/Input Offset Voltage Drift(Vos TC);30nV/℃/Output Current;65mA/Rail to Rail;Rail-to-Rail Input, Rail-to-Rail Output/Noise density(eN);38nV/√Hz@1kHz/Single Supply;1.8V~5.5V/Dual Supply;-2.75V~-900mV;900mV~2.75V/Input Offset Current(Ios);10pA


30uV Rail-to-Rail Input, Rail-to-Rail Output 20pA 0.95V/us 110dB 180uA 1.8MHz Four channels SOIC-14 Amplifiers RoHS

Product form

Number of Channels;Four channels/Quiescent Current;180uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;1.8MHz/Common Mode Rejection Ratio(CMRR);110dB/Ib - Input Bias Current;20pA/Vos - Input Offset Voltage;30uV/Slew Rate;0.95V/us/Input... Read more

$7.71 Excl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Number of Channels;Four channels/Quiescent Current;180uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;1.8MHz/Common Mode Rejection Ratio(CMRR);110dB/Ib - Input Bias Current;20pA/Vos - Input Offset Voltage;30uV/Slew Rate;0.95V/us/Input Offset Voltage Drift(Vos TC);30nV/℃/Output Current;65mA/Rail to Rail;Rail-to-Rail Input, Rail-to-Rail Output/Noise density(eN);38nV/√Hz@1kHz/Single Supply;1.8V~5.5V/Dual Supply;-2.75V~-900mV;900mV~2.75V/Input Offset Current(Ios);10pA


    30uV Rail-to-Rail Input, Rail-to-Rail Output 20pA 0.95V/us 110dB 180uA 1.8MHz Four channels SOIC-14 Amplifiers RoHS
