HXY MOSFET-Amplifiers-HAD8542ARZ

Description

Number of Channels;2/Quiescent Current;85uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;1.2MHz/Common Mode Rejection Ratio(CMRR);83dB/Maximum Power Supply Range (Vdd-Vss);5.5V/Ib - Input Bias Current;5pA/Vos - Input Offset Voltage;3mV/Slew Rate;1V/us/Input Offset Voltage Drift(Vos TC);1uV/℃/Output Current;40mA/Rail to Rail;Rail-to-Rail Input, Rail-to-Rail Output/Noise density(eN);30nV/√Hz@1kHz/Single Supply;2.2V~5.5V/Dual Supply;-3V~-1V;1V~3V


3mV Rail-to-Rail Input, Rail-to-Rail Output 5pA 1V/us 83dB 85uA 1.2MHz 2 SOP-8L Amplifiers RoHS

Product form

Number of Channels;2/Quiescent Current;85uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;1.2MHz/Common Mode Rejection Ratio(CMRR);83dB/Maximum Power Supply Range (Vdd-Vss);5.5V/Ib - Input Bias Current;5pA/Vos - Input... Read more

$4.26 Excl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Number of Channels;2/Quiescent Current;85uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;1.2MHz/Common Mode Rejection Ratio(CMRR);83dB/Maximum Power Supply Range (Vdd-Vss);5.5V/Ib - Input Bias Current;5pA/Vos - Input Offset Voltage;3mV/Slew Rate;1V/us/Input Offset Voltage Drift(Vos TC);1uV/℃/Output Current;40mA/Rail to Rail;Rail-to-Rail Input, Rail-to-Rail Output/Noise density(eN);30nV/√Hz@1kHz/Single Supply;2.2V~5.5V/Dual Supply;-3V~-1V;1V~3V


    3mV Rail-to-Rail Input, Rail-to-Rail Output 5pA 1V/us 83dB 85uA 1.2MHz 2 SOP-8L Amplifiers RoHS
