RUNIC-Amplifiers-RS8522XTDE8

Description

Number of Channels;2/Quiescent Current;60uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;350kHz/Common Mode Rejection Ratio(CMRR);130dB/Ib - Input Bias Current;10pA/Vos - Input Offset Voltage;1uV/Slew Rate;0.17V/us/Input Offset Voltage Drift(Vos TC);5nV/℃/Output Current;25mA/Rail to Rail;Rail-to-Rail Input, Rail-to-Rail Output/Noise density(eN);140nV/√Hz@1kHz/Features;Zero drift/automatic zero stabilization;Reverse-phase input protection;Built-in compensation/Single Supply;2.3V~5.5V/Dual Supply;-2.75V~-1.15V;1.15V~2.75V/Input Offset Current(Ios);10pA


1uV Rail-to-Rail Input, Rail-to-Rail Output 10pA 0.17V/us 130dB 60uA 350kHz 2 TDFN-8L(2x2) Amplifiers RoHS

Product form

Number of Channels;2/Quiescent Current;60uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;350kHz/Common Mode Rejection Ratio(CMRR);130dB/Ib - Input Bias Current;10pA/Vos - Input Offset Voltage;1uV/Slew Rate;0.17V/us/Input Offset... Read more

$2.34 Excl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Number of Channels;2/Quiescent Current;60uA/Operating Temperature;-40℃~+125℃/Gain Bandwidth Product;350kHz/Common Mode Rejection Ratio(CMRR);130dB/Ib - Input Bias Current;10pA/Vos - Input Offset Voltage;1uV/Slew Rate;0.17V/us/Input Offset Voltage Drift(Vos TC);5nV/℃/Output Current;25mA/Rail to Rail;Rail-to-Rail Input, Rail-to-Rail Output/Noise density(eN);140nV/√Hz@1kHz/Features;Zero drift/automatic zero stabilization;Reverse-phase input protection;Built-in compensation/Single Supply;2.3V~5.5V/Dual Supply;-2.75V~-1.15V;1.15V~2.75V/Input Offset Current(Ios);10pA


    1uV Rail-to-Rail Input, Rail-to-Rail Output 10pA 0.17V/us 130dB 60uA 350kHz 2 TDFN-8L(2x2) Amplifiers RoHS
